LMC & BMC-317

El LMC / BMC-317 es un compresor centrífugo de una sola etapa con engranajes integrales que ofrece un rendimiento multietapa. Construido para cumplir con las exigentes normas API-617 / ISO 10439

Soluciones: Gas y Petróleo, Energía, Química
Descripcion General
  • Maximum Flow                3,550 acfm         6,030 am³/hr
  • Maximum Speed             34,200 rpm-60Hz             33,600 rpm-50Hz
  • Maximum Working Pressure      1,200 psi             85 bar
  • Temperature Range       -200 to 500°F     -130 to 260°C
  • Maximum Motor Size    200 hp  149 kW
  • Hydro Test Pressure       1.5 Times Maximum Working Pressure
  • Min Casing Thickness     0.75 in  19.05 mm
  • Corrosion Allowance      0.125 in               3.18 mm
  • Impeller Clearance          0.03 to 0.05in    .76 to 1.27mm
  • Shaft Diameter at Bearings          1.5in (38.1mm)
  • Mechanical Seal Sizes-Outboard…          1.25 in  31.8 mm
  • Mechanical Seal Sizes-Inboard 1.5 in     38.1 mm
  • Mounting            Vertical or Horizontal
  • Flanges                600# ANSI RF standard, other ratings available
  • Suction Flange 8 inch
  • Discharge Flange              6 inch
  • Gearbox Oil Temp Range (normal…        120 to 180°F      49 to 82°C
  • Minimum Gearbox Starting Temp            32°f (0°C) with light turbine oil, lower with approved synthetic oil
  • Gearbox Lubricant           ISO VG-32 General Purpose OIl
  • Gearbox Sump Capacity                7 Quarts (6.6 Liters)
  • Gearbox Lube System    Pressurized
  • Gears    Hardened and precision ground, helical and/or spur
  • Input and Idler Bearings               Deep Groove, angular contact or solid journal as required
  • Output Bearings               Solid Journal or tilt pad thrust and radial as required
  • Coupling              Spline, standard flexible or space type
  • Materials of Construction            Castings:Carbon Steel, Stainless steel; Impeller: 17-4PHSS, Titanium
Información Técnica
  • Flujo hasta 3.550 ACFM (6.030 AM³/hr)
  • Max Presion de Trabajo 1.200 psia (85 bar)
  • Power 149 kW
